Jabiru Engine 2200 Series Parts Book
$19.95
Description
Jabiru Engine
2200 Series
From Serial Number 22A225
Applicable to Jabiru 2200A, 2200B & 2200J Models
Parts Book
has 64 pages
June 2001
contents
Section Description
A Cylinder Head
B Crankcase Crankshaft and Camshaft
C Conrod Piston and Barrel
D Valves Assembly
E Lubrication System
F Flywheel and Ignition
G Induction System
H Engine Mount and Fittings
I Exhaust and Muffler
J Gearbox Assembly
K Starter Motor
L Sump Dipstick and Breather
M Rocker Lubrication and Venting
N Carburettor Assembly
O Miscellaneous Electrical
P Air Cooling Ducts
Appendix for engines up to 22A224
